Твердосплавный инструмент для станков с ЧПУ


DUO-LOCK™ • HARVI™ I • Radiused • 4 Flutes • InchHARVI • ULDV • Asymmetrical Flute Spacing
Asymmetrical flute spacing and variable helix configuration minimize chatter and harmonics for smoother machining.;Center cutting.;Single tool for both roughing and finishing’ reducing setups.;Standard items listed. Additional styles and coatings made-to-order.
Обрабатываемый материал:


Stainless Steel

Cast Iron

High-Temp Alloys

Hardened Materials

SAP Material Number 6072363
ISO Catalog Number ULDV0750Y4CQD
Grade KCSM15
Adapter Style Machine Side DUO-LOCK
[D] Adapter / Shank / Bore Diameter 25.4 mm
[L1] Gage Length 42.9 mm
[CSMS] System Size Machine Side DL20
[WF] Width of Flat 16 mm
[Re] Corner Radius 2.286 mm
[Z] Number of Flutes 4
[D1] Effective Cutting Diameter 19.05 mm
[AP1MAX] 1st Maximum Cutting Depth 28.575 mm
