UJBE1000N6DB KCSM15
HARVI™ III Aero • Ball Nose • 6 Flutes • Safe-Lock™ Shank • InchHARVI™ III Aero Solid Carbide End Mill for High Feed Roughing and Finishing with Maximum Metal Removal Rates
Характеристики:
Versatile solid carbide end mill for stainless steel’ and high-temperature alloys.;HARVI™ III Aero solid carbide end mills cover a variety of operations.;HARVI™ III Aero solid carbide end mills feature unequal flute spacing for chatter-free machining at highest feed rates.;Eccentric relief grind for higher edge stability and higher feed rates.;Centre cutting for plunging and ramping operations.
Обрабатываемый материал:
Steel
Stainless Steel
High-Temp Alloys
Hardened Materials
SAP Material Number | 6113865 |
ISO Catalog Number | UJBE1000N6DB |
Grade | KCSM15 |
Adapter Style Machine Side | SAFE-LOCK |
[Z] Number of Flutes | 6 |
[D1] Effective Cutting Diameter | 25.4 mm |
[D] Adapter / Shank / Bore Diameter | 25.4 mm |
[AP1MAX] 1st Maximum Cutting Depth | 101.6 mm |
[L] Overall Length | 177.8 mm |
