KSDB0500Y6BQX KC643M
DUO-LOCK™ • KenFEED™ • KSDB • Radiused • 6 Flutes • InchDUO-LOCK™ • KenFeed™ • 6 Flutes
Характеристики:
Обрабатываемый материал:
Steel
Stainless Steel
High-Temp Alloys
| SAP Material Number | 6626761 |
| ISO Catalog Number | KSDB0500Y6BQX |
| Grade | KC643M |
| Adapter Style Machine Side | DUO-LOCK |
| [D] Adapter / Shank / Bore Diameter | 12.2 mm |
| [AP1MAX] 1st Maximum Cutting Depth | 0.68 mm |
| [L1] Gage Length | 22.25 mm |
| [CSMS] System Size Machine Side | DL12 |
| [WF] Width of Flat | 9.5 mm |
| [Re] Corner Radius | 0.794 mm |
| [Z] Number of Flutes | 6 |
| [D1] Effective Cutting Diameter | 12.7 mm |
