KOR5RA1600R048SLR050CM K600
KOR5™ DA • 5 канавок • 3 X D • Хвостовик SAFE-λOCK® • В метрических единицахKOR5 DA • 5 ЗУБЬЕВ • 3 X D • Хвостовик SAFE-lOCK®
Характеристики:
Designed for trochoidal milling with low radial engagement and full length of cut.;With chip splitters for ideal chip evacuation.;Proprietary flute form reduces vibrations and improves tool life.;Helix angle tailored to minimize vibration and optimize tool life.;Front end geometry designed for maximum tool life in helical and ramping operations.;Safe-Lock for pull out protection.
Обрабатываемый материал:
Non-Ferrous
| SAP Material Number | 6755032 |
| ISO Catalog Number | KOR5RA1600R048SLR050CM |
| Grade | K600 |
| Adapter Style Machine Side | SAFE-LOCK |
| [D1] Effective Cutting Diameter | 16 mm |
| [D] Adapter / Shank / Bore Diameter | 16 mm |
| [AP1MAX] 1st Maximum Cutting Depth | 48 mm |
| [L] Overall Length | 104 mm |
| [Re] Corner Radius | 0.5 mm |
| [Z] Number of Flutes | 5 |
