KOR5RA0375R113HAR030 KC643M

KOR5™ DS • Radiused • 5 Flutes • 3 x D • Plain Shank • InchKOR5™ DS Solid Carbide End Mill for Dynamic Milling of Steel and Stainless Steel
Designed for trochoidal milling with low radial engagement and full length of cut.;With chip deformers for ideal chip evacuation at high surface quality.;Proprietary flute form reduces vibrations and improves tool life.;Helix angle tailored to minimize vibration and optimize tool life.;Front end geometry designed for maximum tool life in helical and ramping operations.
Обрабатываемый материал:


Stainless Steel

Cast Iron

High-Temp Alloys

Hardened Materials

SAP Material Number 6769781
ISO Catalog Number KOR5RA0375R113HAR030
Grade KC643M
Adapter Style Machine Side Straight-Cylindrical
[Re] Corner Radius 0.762 mm
[Z] Number of Flutes 5
[D1] Effective Cutting Diameter 9.525 mm
[D] Adapter / Shank / Bore Diameter 9.525 mm
[AP1MAX] 1st Maximum Cutting Depth 28.575 mm
[L] Overall Length 76.2 mm
