Твердосплавный инструмент для станков с ЧПУ

HPRST750S6150 KC643M

KenCut™ RR • HPRST • Radiused • 4-6 Flutes • Weldon® Shank • InchSolid Carbide End Mill for Roughing of Stainless Steel’ High-Temperature Alloys’ and Hard Materials.
Centre cutting for plunging and ramping operations.;Solid carbide end mill with flat shallow profile’ offering a good compromise between surface finish and power consumption.
Обрабатываемый материал:


Stainless Steel

Cast Iron

High-Temp Alloys

Hardened Materials

SAP Material Number 3331492
ISO Catalog Number HPRST750S6150
Grade KC643M
Adapter Style Machine Side Weldon
[Re] Corner Radius 1.27 mm
[Z] Number of Flutes 6
[D1] Effective Cutting Diameter 19.05 mm
[D] Adapter / Shank / Bore Diameter 19.05 mm
[AP1MAX] 1st Maximum Cutting Depth 38.1 mm
[L3] Usable Length 38.1 mm
[L] Overall Length 101.6 mm
