HPRST750S4088 KC643M
KenCut™ RR • HPRST • Radiused • 4-6 Flutes • Weldon® Shank • InchSolid Carbide End Mill for Roughing of Stainless Steel’ High-Temperature Alloys’ and Hard Materials.
Характеристики:
Centre cutting for plunging and ramping operations.;Solid carbide end mill with flat shallow profile’ offering a good compromise between surface finish and power consumption.
Обрабатываемый материал:
Steel
Stainless Steel
Cast Iron
High-Temp Alloys
Hardened Materials
| SAP Material Number | 3331490 |
| ISO Catalog Number | HPRST750S4088 |
| Grade | KC643M |
| Adapter Style Machine Side | Weldon |
| [Re] Corner Radius | 1.27 mm |
| [Z] Number of Flutes | 4 |
| [D1] Effective Cutting Diameter | 19.05 mm |
| [D] Adapter / Shank / Bore Diameter | 19.05 mm |
| [AP1MAX] 1st Maximum Cutting Depth | 22.225 mm |
| [L3] Usable Length | 22.225 mm |
| [L] Overall Length | 88.9 mm |
