HPHV750S4163R060 KCPM15
HARVI™ I • Radiused • 4 Flutes • Weldon® Shank • InchHARVI™ I Solid Carbide End Mill for Roughing and Finishing of Multiple Materials
Характеристики:
Versatile solid carbide end mill for steels’ stainless steel’ cast iron’ and high temperature alloys.;HARVI™ I solid carbide end mills cover a variety of operations’ including dynamic milling.;HARVI™ I solid carbide end mills features unequal flute spacing for chatter-free machining.;Centre cutting for plunging and ramping operations.
Обрабатываемый материал:
Steel
Stainless Steel
Cast Iron
Hardened Materials
| SAP Material Number | 4067282 |
| ISO Catalog Number | HPHV750S4163R060 |
| Grade | KCPM15 |
| Adapter Style Machine Side | Weldon |
| [Re] Corner Radius | 1.524 mm |
| [Z] Number of Flutes | 4 |
| [D1] Effective Cutting Diameter | 19.05 mm |
| [D] Adapter / Shank / Bore Diameter | 19.05 mm |
| [AP1MAX] 1st Maximum Cutting Depth | 41.275 mm |
| [L3] Usable Length | 41.275 mm |
| [L] Overall Length | 101.6 mm |
