HPHV500S4150R060 KCPM15

HARVI™ I • Radiused • 4 Flutes • Weldon® Shank • InchHARVI™ I Solid Carbide End Mill for Roughing and Finishing of Multiple Materials
Versatile solid carbide end mill for steels’ stainless steel’ cast iron’ and high temperature alloys.;HARVI™ I solid carbide end mills cover a variety of operations’ including dynamic milling.;HARVI™ I solid carbide end mills features unequal flute spacing for chatter-free machining.;Centre cutting for plunging and ramping operations.
Обрабатываемый материал:


Stainless Steel

Cast Iron

Hardened Materials

SAP Material Number 4071922
ISO Catalog Number HPHV500S4150R060
Grade KCPM15
Adapter Style Machine Side Weldon
[Re] Corner Radius 1.524 mm
[Z] Number of Flutes 4
[D1] Effective Cutting Diameter 12.7 mm
[D] Adapter / Shank / Bore Diameter 12.7 mm
[AP1MAX] 1st Maximum Cutting Depth 38.1 mm
[L3] Usable Length 38.1 mm
[L] Overall Length 101.6 mm
