Твердосплавный инструмент для станков с ЧПУ

HPHV1000S4225 KCPM15

HARVI™ I • Square End • 4 Flutes • Weldon® Shank • InchHARVI™ I Solid Carbide End Mill for Roughing and Finishing of Multiple Materials
Характеристики:
Versatile solid carbide end mill for steels’ stainless steel’ cast iron’ and high temperature alloys.;HARVI™ I solid carbide end mills cover a variety of operations’ including dynamic milling.;HARVI™ I solid carbide end mills features unequal flute spacing for chatter-free machining.;Centre cutting for plunging and ramping operations.
Обрабатываемый материал:

Steel

Stainless Steel

Cast Iron

Hardened Materials

SAP Material Number 4067318
ISO Catalog Number HPHV1000S4225
Grade KCPM15
Adapter Style Machine Side Weldon
[Z] Number of Flutes 4
[D1] Effective Cutting Diameter 25.4 mm
[D] Adapter / Shank / Bore Diameter 25.4 mm
[AP1MAX] 1st Maximum Cutting Depth 57.15 mm
[L3] Usable Length 57.15 mm
[L] Overall Length 127 mm
