HA4R8SE1000R250HAD KCSM15A
HARVI™ IV • Square End • 8 Flutes • Internal Coolant • Chipbreaker • Plain Shank • InchHARVI™ IV Eight Flute End Mill for Roughing and FinishingCovering the Broadest Range of Applications and Materials
Характеристики:
Single tool for roughing and finishing to reduce tool setups.;Proprietary core and flute design with optimum flute spacing for perfect chip formation and highest tool rigidity.;Developed for highest productivity in titanium’ high-temperature alloys’ and stainless steels.;With chip breakers for optimized chip evacuation.
Обрабатываемый материал:
Steel
Stainless Steel
High-Temp Alloys
Hardened Materials
| SAP Material Number | 7102915 |
| ISO Catalog Number | HA4R8SE1000R250HAD |
| Grade | KCSM15A |
| Adapter Style Machine Side | Straight-Cylindrical |
| [Z] Number of Flutes | 8 |
| [D1] Effective Cutting Diameter | 25.4 mm |
| [D] Adapter / Shank / Bore Diameter | 25.4 mm |
| [AP1MAX] 1st Maximum Cutting Depth | 63.5 mm |
| [L] Overall Length | 139.7 mm |
