HA4R8RA0750S100SLR030I KCSM15A

HARVI™ IV • Radiused • 8 Flutes • Internal Coolant • Safe-LockTM Shank • InchHARVI™ IV Eight Flute End Mill for Roughing and FinishingCovering the Broadest Range of Applications and Materials
Single tool for roughing and finishing to reduce tool setups.;Proprietary core and flute design with optimum flute spacing for perfect chip formation and highest tool rigidity.;Developed for highest productivity in titanium’ high-temperature alloys’ and stainless steels.;With Safe-Lock for pull-out protection.
Обрабатываемый материал:


Stainless Steel

High-Temp Alloys

Hardened Materials

SAP Material Number 7102528
ISO Catalog Number HA4R8RA0750S100SLR030I
Grade KCSM15A
Adapter Style Machine Side SAFE-LOCK
[Re] Corner Radius 0.762 mm
[Z] Number of Flutes 8
[D1] Effective Cutting Diameter 19.05 mm
[D] Adapter / Shank / Bore Diameter 19.05 mm
[AP1MAX] 1st Maximum Cutting Depth 25.4 mm
[L] Overall Length 88.9 mm
