HARVI™ III • Ball Nose • 6 Flutes • Plain Shank • InchHARVI™ III Solid Carbide End Mill for 3D Profiling with Highest Productivity
Versatile solid carbide end mill for steels’ stainless steel’ and high-temperature alloys.;HARVI™ III solid carbide end mills cover a variety of operations.;HARVI™ III solid carbide end mills feature unequal flute spacing for chatter-free machining at highest feed rates.;Eccentric relief grind for higher edge stability and higher feed rates.;Centre cutting for plunging and ramping operations.
Обрабатываемый материал:


Stainless Steel

High-Temp Alloys

Hardened Materials

SAP Material Number 7077555
ISO Catalog Number HA3R6BN0625R125HA
Grade KCSM15A
Adapter Style Machine Side Straight-Cylindrical
[Z] Number of Flutes 6
[D1] Effective Cutting Diameter 15.875 mm
[D] Adapter / Shank / Bore Diameter 15.875 mm
[AP1MAX] 1st Maximum Cutting Depth 31.75 mm
[L] Overall Length 88.9 mm
