HA3A6BN1000S150SL KCSM15A
HARVI™ III Aero • Ball Nose • 6 Flutes • Safe-Lock™ Shank • InchHARVI™ III Aero Solid Carbide End Mill for High Feed Roughing and Finishing with Maximum Metal Removal Rates
Характеристики:
Versatile solid carbide end mill for stainless steel’ and high-temperature alloys.;HARVI™ III Aero solid carbide end mills cover a variety of operations.;HARVI™ III Aero solid carbide end mills feature unequal flute spacing for chatter-free machining at highest feed rates.;Eccentric relief grind for higher edge stability and higher feed rates.;Centre cutting for plunging and ramping operations.
Обрабатываемый материал:
Steel
Stainless Steel
High-Temp Alloys
Hardened Materials
| SAP Material Number | 7077145 |
| ISO Catalog Number | HA3A6BN1000S150SL |
| Grade | KCSM15A |
| Adapter Style Machine Side | SAFE-LOCK |
| [Z] Number of Flutes | 6 |
| [D1] Effective Cutting Diameter | 25.4 mm |
| [D] Adapter / Shank / Bore Diameter | 25.4 mm |
| [AP1MAX] 1st Maximum Cutting Depth | 38.1 mm |
| [L] Overall Length | 114.3 mm |
