HA3A6BN0750L300HA KCSM15A
HARVI™ III Aero • Ball Nose • 6 Flutes • Plain Shank • InchHARVI™ III Aero Solid Carbide End Mill for High Feed Roughing and Finishing with Maximum Metal Removal Rates
Характеристики:
Versatile solid carbide end mill for stainless steel’ and high-temperature alloys.;HARVI™ III Aero solid carbide end mills cover a variety of operations.;HARVI™ III Aero solid carbide end mills feature unequal flute spacing for chatter-free machining at highest feed rates.;Eccentric relief grind for higher edge stability and higher feed rates.;Centre cutting for plunging and ramping operations.
Обрабатываемый материал:
Steel
Stainless Steel
High-Temp Alloys
Hardened Materials
SAP Material Number | 7077143 |
ISO Catalog Number | HA3A6BN0750L300HA |
Grade | KCSM15A |
Adapter Style Machine Side | Straight-Cylindrical |
[Z] Number of Flutes | 6 |
[D1] Effective Cutting Diameter | 19.05 mm |
[D] Adapter / Shank / Bore Diameter | 19.05 mm |
[AP1MAX] 1st Maximum Cutting Depth | 76.2 mm |
[L] Overall Length | 139.7 mm |
