H1TE4RA0375R056DLR060 KCSM15

DUO-LOCK™ • HARVI™ I TE • Radiused • 4 Flutes • InchHARVI™ I TE Four Flute End Mill for Roughing and Finishing Covering the Broadest Range of Applications and Materials
Versatile modular end mill for steels’ stainless steel’ cast iron’ and high temperature alloys.;Covers a variety of operations’ including dynamic milling’ and extreme ramping operations.;Maximum metal removal’ maximum productivity’ maximum benefit.;Asymmetrical divided flutes’ variable helix’ twisted end face’ facteted eccentric relief’ and chip gashes within the flutes.;Centre cutting for plunging and ramping operations.
Обрабатываемый материал:


Stainless Steel

Cast Iron

High-Temp Alloys

Hardened Materials

SAP Material Number 7136469
ISO Catalog Number H1TE4RA0375R056DLR060
Grade KCSM15
Adapter Style Machine Side DUO-LOCK
[D] Adapter / Shank / Bore Diameter 9.125 mm
[L1] Gage Length 21.4 mm
[CSMS] System Size Machine Side DL10
[WF] Width of Flat 8 mm
[Re] Corner Radius 1.524 mm
[Z] Number of Flutes 4
[D1] Effective Cutting Diameter 9.525 mm
[AP1MAX] 1st Maximum Cutting Depth 14.288 mm
