H1TE4CH0400N011HAM KCPM15
HARVI™ I TE • С фаской • 4 ЗУБА • С шейкойHARVI™ I TE • С фаской • 4 ЗУБА • С шейкой • Цилиндрический хвостовик
Характеристики:
Versatile solid carbide end mill for steels’ stainless steel’ cast iron’ and high temperature alloys.;HARVI™ I TE solid carbide end mills cover a variety of operations’ including dynamic milling’ and extreme ramping operations.;HARVI™ I TE solid carbide end mills stand for maximum metal removal’ maximum productivity’ maximum benefit.;HARVI™ I TE solid carbide end mills feature asymmetrical divided flutes’ variable helix’ twisted end face’ facteted eccentric relief’ and chip gashes within the flutes.;Centre cutting for plunging and ramping operations.
Обрабатываемый материал:
Steel
Stainless Steel
Cast Iron
High-Temp Alloys
Hardened Materials
| SAP Material Number | 6676308 |
| ISO Catalog Number | H1TE4CH0400N011HAM |
| Grade | KCPM15 |
| Adapter Style Machine Side | Straight-Cylindrical |
| [D1] Effective Cutting Diameter | 4 mm |
| [D] Adapter / Shank / Bore Diameter | 6 mm |
| [D3] Neck Diameter | 3.76 mm |
| [AP1MAX] 1st Maximum Cutting Depth | 11 mm |
| [L3] Usable Length | 16 mm |
| [L] Overall Length | 57 mm |
| [BCH] Corner Chamfer Width | 0.15 mm |
| [Z] Number of Flutes | 4 |
