ABDE1000Y3CQE K600

DUO-LOCK™ • MaxiMet™ • Radiused • 3 Flutes • InchMaxiMet • ABDE • Wiper Facet • Unequal Flute Spacing
Center cutting.;Optimized for thin-wall applications.;Wiper facet’ special end gash’ and flute geometry enable improved surface finishes.;Standard items listed. Additional styles and coatings made-to-order.
Обрабатываемый материал:


SAP Material Number 6153970
ISO Catalog Number ABDE1000Y3CQE
Grade K600
Adapter Style Machine Side DUO-LOCK
[D] Adapter / Shank / Bore Diameter 24.4 mm
[L1] Gage Length 57.2 mm
[CSMS] System Size Machine Side DL25
[WF] Width of Flat 21 mm
[Re] Corner Radius 3.048 mm
[Z] Number of Flutes 3
[D1] Effective Cutting Diameter 25.4 mm
[AP1MAX] 1st Maximum Cutting Depth 38.1 mm
