4CH0750IX400A KC633M
GOmill™ GP • Chamfered • 4 Flutes • Plain Shank • InchGeneral Purpose Solid Carbide End Mill
Характеристики:
Solid carbide end mill with excellent cost-benefit ratio.;Eccentric relief increases cutting edge stability for long tool life and high surface quality.;Eccentric relief eases regrinding and reduces reconditioning cost.;Center cutting for plunging and ramping operations.
Обрабатываемый материал:
Steel
Stainless Steel
Cast Iron
| SAP Material Number | 5824412 |
| ISO Catalog Number | 4CH0750IX400A |
| Grade | KC633M |
| Adapter Style Machine Side | Straight-Cylindrical |
| [BCH] Corner Chamfer Width | 0.508 mm |
| [Z] Number of Flutes | 4 |
| [D1] Effective Cutting Diameter | 19.05 mm |
| [D] Adapter / Shank / Bore Diameter | 19.05 mm |
| [AP1MAX] 1st Maximum Cutting Depth | 101.6 mm |
| [L] Overall Length | 177.8 mm |
