4BN0219IR062A KC633M
GOmill™ GP • Ball Nose • 4 Flutes • Plain Shank • InchGeneral Purpose Solid Carbide End Mill
Характеристики:
Solid carbide end mill with excellent cost-benefit ratio.;Eccentric relief increases cutting edge stability for long tool life and high surface quality.;Eccentric relief eases regrinding and reduces reconditioning cost.;Center cutting for plunging and ramping operations.
Обрабатываемый материал:
Steel
Stainless Steel
Cast Iron
| SAP Material Number | 5824517 |
| ISO Catalog Number | 4BN0219IR062A |
| Grade | KC633M |
| Adapter Style Machine Side | Straight-Cylindrical |
| [Z] Number of Flutes | 4 |
| [D1] Effective Cutting Diameter | 5.556 mm |
| [D] Adapter / Shank / Bore Diameter | 6.35 mm |
| [AP1MAX] 1st Maximum Cutting Depth | 15.875 mm |
| [L] Overall Length | 63.5 mm |
