Твердосплавный инструмент для станков с ЧПУ

2BN0750IL200A KC633M

GOmill™ GP • Ball Nose • 2 Flutes • Plain Shank • InchGeneral Purpose Solid Carbide End Mill
Характеристики:
Solid carbide end mill with excellent cost-benefit ratio.;Eccentric relief increases cutting edge stability for long tool life and high surface quality.;Eccentric relief eases regrinding and reduces reconditioning cost.;Center cutting for plunging and ramping operations.
Обрабатываемый материал:

Steel

Stainless Steel

Cast Iron

SAP Material Number 5876772
ISO Catalog Number 2BN0750IL200A
Grade KC633M
Adapter Style Machine Side Straight-Cylindrical
[Z] Number of Flutes 2
[D1] Effective Cutting Diameter 19.05 mm
[D] Adapter / Shank / Bore Diameter 19.05 mm
[AP1MAX] 1st Maximum Cutting Depth 50.8 mm
[L] Overall Length 152.4 mm
