14D-F45XNH-R-09
45 Face mills with carbide shim and double-sided 14 cutting edges inserts of XN 09 for roughing of difficult-to-cut material & heavy milling
| Designation | DC | CICT | DCX | DCONMS | DHUB | OAL | APMX | CSP | Arbor | kg | MIID |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 14D-F45XNH 563-22R-09 | 63.00 | 5 | 75.04 | 22.00 | 47.00 | 50.00 | 5.00 | O | A | 0.60 | XNHU 0906 ANTN-MM |
| 14D-F45XNH 680-27R-09 | 80.00 | 6 | 92.10 | 27.00 | 70.00 | 50.00 | 5.00 | O | A | 1.50 | XNHU 0906 ANTN-MM |
| 14D-F45XNH 7100-32R-09 | 100.00 | 7 | 112.10 | 32.00 | 85.00 | 50.00 | 5.00 | O | A | 2.20 | XNHU 0906 ANTN-MM |
| 14D-F45XNH 9125-40R-09 | 125.00 | 9 | 137.00 | 40.00 | 85.00 | 63.00 | 5.00 | O | A | 3.60 | XNHU 0906 ANTN-MM |
