14D-F45XN-R-09
45 Face mills with double-sided economical 14 cutting edges inserts of XN 09 for roughing of steels & cast irons
| Designation | DC | CICT | DCX | DCONMS | DHUB | OAL | APMX | Arbor | CSP | WT | MIID |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 14D-F45XN 563-22R-09 | 63.00 | 5 | 74.90 | 22.00 | 47.00 | 50.00 | 5.00 | A | O | 0.85 | XNHU 0906 ANTN-MM |
| 14D-F45XN 663-22R-09 | 63.00 | 6 | 75.05 | 22.00 | 47.00 | 50.00 | 5.00 | A | O | 0.86 | XNHU 0906 ANTN-MM |
| 14D-F45XN 680-25.4R-09 | 80.00 | 6 | 92.05 | 25.40 | 70.00 | 50.00 | 5.00 | A | O | 1.44 | XNHU 0906 ANTN-MM |
| 14D-F45XN 680-27R-09 | 80.00 | 6 | 91.90 | 27.00 | 70.00 | 50.00 | 5.00 | A | O | 1.44 | XNHU 0906 ANTN-MM |
| 14D-F45XN 780-27R-09 | 80.00 | 7 | 91.90 | 27.00 | 70.00 | 50.00 | 5.00 | A | O | 1.46 | XNHU 0906 ANTN-MM |
| 14D-F45XN 7100-31.75R-09 | 100.00 | 7 | 112.00 | 31.75 | 80.00 | 55.00 | 5.00 | A | O | 2.42 | XNHU 0906 ANTN-MM |
| 14D-F45XN 7100-32R-09 | 100.00 | 7 | 112.00 | 32.00 | 85.00 | 55.00 | 5.00 | A | O | 2.42 | XNHU 0906 ANTN-MM |
| 14D-F45XN 9100-32R-09 | 100.00 | 9 | 112.00 | 32.00 | 85.00 | 55.00 | 5.00 | A | O | 2.46 | XNHU 0906 ANTN-MM |
| 14D-F45XN 10125-40R-09 | 125.00 | 10 | 137.00 | 40.00 | 85.00 | 63.00 | 5.00 | A | O | 3.55 | XNHU 0906 ANTN-MM |
| 14D-F45XN 12125-40R-09 | 125.00 | 12 | 137.00 | 40.00 | 85.00 | 63.00 | 5.00 | A | O | 3.36 | XNHU 0906 ANTN-MM |
| 14D-F45XN 8125-38.1R-09 | 125.00 | 8 | 137.00 | 38.10 | 80.00 | 63.00 | 5.00 | B | X | 3.53 | XNHU 0906 ANTN-MM |
| 14D-F45XN 8125-40R-09 | 125.00 | 8 | 137.00 | 40.00 | 85.00 | 63.00 | 5.00 | A | O | 3.53 | XNHU 0906 ANTN-MM |
| 14D-F45XN 10160-40R-09 | 160.00 | 10 | 172.00 | 40.00 | 110.00 | 63.00 | 5.00 | C | X | 4.77 | XNHU 0906 ANTN-MM |
| 14D-F45XN 10160-50.8R-09 | 160.00 | 10 | 172.00 | 50.80 | 100.00 | 63.00 | 5.00 | B | X | 4.77 | XNHU 0906 ANTN-MM |
| 14D-F45XN 12160-40R-09 | 160.00 | 12 | 172.00 | 40.00 | 110.00 | 63.00 | 5.00 | C | X | 4.79 | XNHU 0906 ANTN-MM |
| 14D-F45XN 14160-40R-09 | 160.00 | 14 | 172.00 | 40.00 | 110.00 | 63.00 | 5.00 | C | X | 4.80 | XNHU 0906 ANTN-MM |
| 14D-F45XN 12200-47.625R09 | 200.00 | 12 | 212.05 | 47.63 | 130.00 | 63.00 | 5.00 | C | X | 6.83 | XNHU 0906 ANTN-MM |
| 14D-F45XN 12200-60R-09 | 200.00 | 12 | 212.00 | 60.00 | 130.00 | 63.00 | 5.00 | C | X | 6.83 | XNHU 0906 ANTN-MM |
| 14D-F45XN 16200-60R-09 | 200.00 | 16 | 212.00 | 60.00 | 130.00 | 63.00 | 5.00 | C | X | 6.85 | XNHU 0906 ANTN-MM |
| 14D-F45XN 16250-60R-09 | 250.00 | 16 | 262.00 | 60.00 | 160.00 | 63.00 | 5.00 | C | X | 11.46 | XNHU 0906 ANTN-MM |
| 14D-F45XN 20250-60R-09 | 250.00 | 20 | 262.00 | 60.00 | 160.00 | 63.00 | 5.00 | C | X | 11.51 | XNHU 0906 ANTN-MM |
