Артикул: 230358
230358
| Cantilever length (LPR) | 153.00 mm |
|---|---|
| Functional length (LF) | 120.00 mm |
| Functional width (WF) | 0.00 mm |
| Product group | Tool holders and adapter |
| Product type | Tool adapter |
| Shank size | VDI40 |
| Interface size | VDI40 |
| Convertible | No |
| Rotatable main &’ counter spindle | yes |
| Tool orientation | 90° |
| Alignment system | Pin (Bar) |
