20.3032LCTXTF - Boringbar holder, Shank- ?30, hole -? 32 mm

Boring bar holder, slotted Premium class tooling system for highest production efficiency - Made in GermanyTrifix© (TF) alignment systemTool completely presetFaster setup of your machineRepeatability &lt 6µm at 200mm throat depthPositioning accuracy of 0.01mm from one station to another

19.4040LCTXRLTFZ-12 - Tool adaptor, hole-? 40 mm, long version, Double serration, adjusting system for trifix turret, offset -12mm, right

Boring Bar Holder Premium class tooling system for highest production efficiency - Made in GermanyDouble toothing (Traub license)VDI shank double toothed.Tool holder can be rotated 180°.Note: Rotatability may be restricted by alignment systems (e.g. Trifix).Trifix© (TF) alignment systemTool completely presetFaster setup of your machineRepeatability &lt 6µm at 200mm throat depthPositioning accuracy of 0.01mm from one station to another

19.40KM40LCTXRLTFRZ0-PL - Boring bar holder, KM 40 - adapter, long version

Boring bar holder Shank- ?40 KM 40 - adapter long version Sauter Revolver Double serration (Lizenz Traub) adjusting system for trifix turret Z=0 mm Pro-Line (be screwed) Trifix-alignment right

1.2516RLIKW - turning holder lengthwise, Square 16, Double serration, Internal coolant supply,

Square longitudinal holder, right, form C1Premium class tooling system for highest production efficiency - Made in GermanyDouble toothing (Traub license)VDI shank double toothed.Tool holder can be rotated 180°.Note: Rotatability may be restricted by alignment systems (e.g. Trifix).

17.4032CTXX75 - Combi holder for int/ext. cooling, hole -? 32 mm,

Combination holder for internal and external cooling Premium class mold system for highest production efficiency - Made in Germany

19.40KM40LCTXRLTFLZ0-PL - Boring bar holder, KM 40 - adapter, long version

Boring bar holder Shank- ?40 KM 40 - adapter long version Sauter Revolver Double serration (Lizenz Traub) adjusting system for trifix turret Z=0 mm Pro-Line (be screwed) Trifix-alignment left

40.30HSK40G300IKEXZ - Axial drilling and milling head, HSK40 Adaptor, Int. / ext. coolant pmax = 25bar, i = 1:1 (input equal output), [001AGW_10_EXZ],

Axial drilling and milling headPremium class tool system for highest production efficiency - Made in GermanyInternal coolingEquipped with high-quality seal kits that can withstand coolant pressure of up to 25 bar.25 bar maximum coolant pressureNot capable of dry runningChange between external and internal cooling possibleCoolant must be applied to the tool at all times

60.25V3G200RLV - Radial drilling and milling head, EWS - Varia V3 - Adaptor, single groove coupling drive, External coolant supply, i =1:1 direction of rotation inver., V - Plate( Licence INDEX ),

Radial drilling and milling headPremium class tool system for highest production efficiency - Made in GermanyEWS.VariaThe Varia system has meanwhile been replaced by Varia VX. The new system is the logical further development of the successful quick-change system and brings with it various advantages.If you are planning a new acquisition, we recommend that you purchase the current system directly.If you are already using the Varia system in your production, please contact us. An upgrade to the new version may be possible and worthwhile for you.Double toothing (Traub license)VDI shank double toothed.Tool holder can be rotated 180°.Note: Rotatability may be restricted by alignment systems (e.g. Trifix).

80.3025CTXR - Radial drill. and mill. head offset, For collet 250 430E (ER25 ?2-16), DIN 5480 drive, External coolant supply, i = 1:1 (input equal output),

Radial drilling and milling head resetPremium class tooling system for highest production efficiency - Made in GermanyCollet chuck ER25 DIN6499Clamping range ?2-16For collet 250 430EWhen tightening the clamping nut, it is essential to counterhold the tool spindle.Failure to observe the counterholding may result in damage to the gearbox or drive coupling.Maximum tightening torque: 90 Nm

80.4032LDCTXRLIKDI1 - Radial drill. and mill. head offset, For collet 320 470E (ER32 ?3-20), double spindle, long version, DIN 5480 drive, IC/EC Ceramic pmax = 70bar, i = 1:2 (input equal output),

Radial drilling and milling head resetPremium class tooling system for highest production efficiency - Made in GermanyCollet chuck ER32 DIN6499Clamping range ?3-20For collet 320 470EWhen tightening the clamping nut, it is essential to counterhold the tool spindle.Failure to observe the counter-hold can result in damage to the gearbox or drive coupling.Maximum tightening torque: 120 NmDouble toothing (Traub license)VDI shank double toothed.Tool holder can be rotated 180°.Note: Rotatability may be restricted by alignment systems (e.g. Trifix).EWS.HPC-Line (IKC/IKD) - Sealing technology sets standardsCeramic based sealing elements0 - 70 bar coolant pressureDry running capability without restrictionsSpeeds up to 12,000/minUp to 60% reduced heat generationLong service life - low maintenance costsSeal kit for the latest generation of internal coolant supply systems

PH31.1620X30-ZYL - Floating holder, Shank- ?16, For collets 200 428E

Pendulum holder Premium class tooling system for highest production efficiency - Made in GermanyCollet chuck ER20 DIN6499Clamping range ?2-13For collet 200 428EMaximum tightening torque: 75 Nm

60.25V3G200RLIKV - Radial drilling and milling head, EWS - Varia V3 - Adaptor, single groove coupling drive, Int. / ext. coolant pmax = 70bar, i =1:1 direction of rotation inver., V - Plate( Licence INDEX ),

Radial drilling and milling headPremium class tool system for highest production efficiency - Made in GermanyEWS.VariaThe Varia system has meanwhile been replaced by Varia VX. The new system is the logical further development of the successful quick-change system and brings with it various advantages.If you are planning a new acquisition, we recommend that you purchase the current system directly.If you are already using the Varia system in your production, please contact us. An upgrade to the new version may be possible and worthwhile for you.Double toothing (Traub license)VDI shank double toothed.Tool holder can be rotated 180°.Note: Rotatability may be restricted by alignment systems (e.g. Trifix).Internal coolingEquipped with high-quality seal kits that can withstand coolant pressure of up to 70 bar.70 bar maximum coolant pressureNot capable of dry runningChange between external and internal cooling possibleCoolant must be applied to the tool at all times

19.4040LX70 - Tool adaptor, hole-? 40 mm, left hand, X=70mm,

Boring Bar Holder Premium class tooling system for highest production efficiency - Made in Germany

60.4040LCTXRIKTF - Radial drilling and milling head, For collet 400 472E (ER40 ?4-26), long, DIN 5480 drive, Int. / ext. coolant pmax = 70bar, i =1:1 direction of rotation inver., adjusting system for Trifix turret,

Radial drilling and milling headPremium class tool system for highest production efficiency - Made in GermanyCollet chuck ER40 DIN6499Clamping range ?4-26For collet 400 472EWhen tightening the clamping nut, it is essential to counterhold the tool spindle.Failure to observe the counterholding may result in damage to the gearbox or drive coupling.Maximum tightening torque: 160 NmInternal coolingEquipped with high-quality seal kits that can withstand coolant pressure of up to 70 bar.70 bar maximum coolant pressureNot capable of dry runningChange between external and internal cooling possibleCoolant must be applied to the tool at all timesTrifix© (TF) alignment systemTool completely presetFaster setup of your machineRepeatability &lt 6µm at 200mm throat depthPositioning accuracy of 0.01mm from one station to another

16.6032/25 - Multi purpose holder, Square 32/25, DIN 69 880 Form D2, for three tools

Square multiple holder, overhead, shape D1 Premium class tooling system for highest production efficiency - Made in GermanyTechnical featureThree tools can be clamped at the same time.Tool holder can be used for main spindle and counter spindle.Pressure plates are not convertible

50.4032DHAASSL40LX160 - Ax. drill. and mill. head offset, For collet 320 470E (ER32 ?3-20), double spindle, claw coupling drive, External coolant supply, i =1:1 direction of rotation inver., X = 160mm,

Axial drilling and milling head with offset axesPremium class tooling system for highest production efficiency - Made in GermanyCollet chuck ER32 DIN6499Clamping range ?3-20For collet 320 470EWhen tightening the clamping nut, it is essential to counterhold the tool spindle.Failure to observe the counter-hold can result in damage to the gearbox or drive coupling.Maximum tightening torque: 120 Nm

19.60HSK63AL80 - Tool adaptor, HSK 63, [050STAT_10_L80],

Boring Bar Holder Premium class tooling system for highest production efficiency - Made in Germany

60.4040TOEMRIK - Radial drilling and milling head, For collet 400 472E (ER40 ?4-26), crown coupling drive, Int. / ext. coolant pmax = 70bar, i =1:1 direction of rotation inver.,

Radial drilling and milling headPremium class tool system for highest production efficiency - Made in GermanyCollet chuck ER40 DIN6499Clamping range ?4-26For collet 400 472EWhen tightening the clamping nut, it is essential to counterhold the tool spindle.Failure to observe the counterholding may result in damage to the gearbox or drive coupling.Maximum tightening torque: 160 NmInternal coolingEquipped with high-quality seal kits that can withstand coolant pressure of up to 70 bar.70 bar maximum coolant pressureNot capable of dry runningChange between external and internal cooling possibleCoolant must be applied to the tool at all times

17.40C4LDCTXRLTFRZ115/Z-40-PL - Combi holder for int/ext. cooling, Polygon ISO 26623 | PSC 40, double version, long, Double serration, Trifix-alignment right, offset design/Pro-Line (be screwed),

Combination holder for internal and external cooling Premium class mold system for highest production efficiency - Made in GermanyEWS.PSC - standardized interfaceSize PSC 40:Repeatability ? 0.01mmTightening torque 50 NmClamping force 21 kNStandardized adapters available worldwideHigh force transmissionEasy handlingInterface for driven and static toolsExtra short adapters without gripper groove available - talk to us!Double toothing (Traub license)VDI shank double toothed.Tool holder can be rotated 180°.Note: Rotatability may be restricted by alignment systems (e.g. Trifix).Trifix© (TF) alignment systemTool completely presetFaster setup of your machineRepeatability &lt 6µm at 200mm throat depthPositioning accuracy of 0.01mm from one station to another

80.30KM40CTXR - Radial drill. and mill. head offset, Adaptor KM40, Coupling 5480 ( Lizenz Sauter ), External coolant supply, i = 1:1 (input equal output),

Radial drilling and milling head resetPremium class tooling system for highest production efficiency - Made in Germany

RT-R25.100.60.60 - Blank, Shank- ?25,

Toolholder Blank VDI 25 Weight: 2.996

19.3032.2X60L - Tool adaptor, hole -? 32.2 mm, DIN 69 880 Form E2, [050STAT_10_X60L],

Boring Bar Holder Premium class tooling system for highest production efficiency - Made in Germany

WA6060L250-S01 - Adaptor, Shank- ?60, hole -? 60 mm

Weight:

WA5040TOEMRX50Z15-PL - Adaptor, Shank- ?50, hole-? 40 mm

Adaptor VDI 40 adaptor Weight: 6.860

32.50UT10R?K - Infeed / Cut-off tool holder, UTUT10, Right hand overhead,

Cut-off holder Premium class tooling system for highest production efficiency - Made in Germany

31.2500TNC30-S01 - Collet chuck holder, Shank- ?25, collet basic holder

Tool holder for collets Premium class tooling system for highest production efficiency - Made in GermanyTechnical featureCover not convertible.It is not possible to change the machining direction, with the help of the cover, between the main spindle or the counter spindle.

32.4000FLEXRLTF - Infeed / Cut-off tool holder, basic holder for cutting tool, Double serration, adjusting system for trifix turret,

Cut-off holder Premium class tooling system for highest production efficiency - Made in GermanyDouble toothing (Traub license)VDI shank double toothed.Tool holder can be rotated 180°.Note: Rotatability may be restricted by alignment systems (e.g. Trifix).Trifix© (TF) alignment systemTool completely presetFaster setup of your machineRepeatability &lt 6µm at 200mm throat depthPositioning accuracy of 0.01mm from one station to another

WA5040TOEMRLX50Z15-PL-S01 - Adaptor, Shank- ?50, hole-? 40 mm

Double toothing (Traub license)VDI shank double toothed.Tool holder can be rotated 180°.Note: Rotatability may be restricted by alignment systems (e.g. Trifix).

17.2550/32G200RLW-S01 - Combi holder for int/ext. cooling, hole -? 50 mm / 32 mm, Double serration, W - seration (License INDEX ), Special design,

Combination holder for internal and external cooling Premium class mold system for highest production efficiency - Made in GermanyDouble toothing (Traub license)VDI shank double toothed.Tool holder can be rotated 180°.Note: Rotatability may be restricted by alignment systems (e.g. Trifix).

17.4000LCTX-OKCB - Combi holder for int/ext. cooling, [050STAT_03_DR00], long version, [050STAT_10_-OKCB],

Combination holder for internal and external cooling Premium class mold system for highest production efficiency - Made in Germany

17.2507.99LG200RLVTKW96 - Combi holder for int/ext. cooling, hole- ? 7.99 mm, long version, Double serration, V-plate, fixed angel of 96°, Cover not convertible

Combination holder for internal and external cooling Premium class mold system for highest production efficiency - Made in GermanyDouble toothing (Traub license)VDI shank double toothed.Tool holder can be rotated 180°.Note: Rotatability may be restricted by alignment systems (e.g. Trifix).Technical featureCover not convertible.It is not possible to change the machining direction, with the help of the cover, between the main spindle or the counter spindle.

19.4040/20DRX60 - Tool adaptor, hole-? 40/20 mm, double version, right hand,

Boring Bar Holder Premium class tooling system for highest production efficiency - Made in Germany

WA6060L250-S02 - Adaptor, Shank- ?60, hole -? 60 mm

Weight: 5.741

17.3032HIX70 - Combi holder for int/ext. cooling, hole -? 32 mm,

Combination holder for internal and external cooling Premium class mold system for highest production efficiency - Made in Germany

17.3032LCTXS01 - Combi holder for int/ext. cooling, hole -? 32 mm, long version, [050STAT_10_S01],

Combination holder for internal and external cooling Premium class mold system for highest production efficiency - Made in Germany

31.3025DRHV - Collet chuck holder, Shank- ?30, For collets 250 430E

Tool holder for collets Premium class tooling system for highest production efficiency - Made in GermanyCollet chuck ER25 DIN6499Clamping range ?2-16For collet 250 430EMaximum tightening torque: 90 Nm

19.50C5L207L - Tool adaptor, Polygon ISO 26623 | PSC 50, L207, left hand,

Boring Bar Holder Premium class tooling system for highest production efficiency - Made in GermanyEWS.PSC - standardized interfaceSize PSC 50:Repeatability ? 0.01mmTightening torque 70 NmClamping force 27 kNStandardized adapters available worldwideHigh force transmissionEasy handlingInterface for driven and static toolsExtra short adapters without gripper groove available - talk to us!

17.3040LCTXRLZ-40FE - Combi holder for int/ext. cooling, hole-? 40 mm, long version, Double serration, [050STAT_10_Z-40FE], Cover not convertible

Combination holder for internal and external cooling Premium class mold system for highest production efficiency - Made in GermanyDouble toothing (Traub license)VDI shank double toothed.Tool holder can be rotated 180°.Note: Rotatability may be restricted by alignment systems (e.g. Trifix).Technical featureCover not convertible.It is not possible to change the machining direction, with the help of the cover, between the main spindle or the counter spindle.

17.3040CTX-VS - Combi holder for int/ext. cooling, hole-? 40 mm, fixation boring additional,

Combination holder for internal and external cooling Premium class mold system for highest production efficiency - Made in Germany

17.4040MP620-S02 - Combi holder for int/ext. cooling, hole-? 40 mm, Special design,

Combiholder Dia. 40 Weight: 8.395

31.2540G200R - Collet chuck holder, Shank- ?25, For collets 400 472E

Tool holder for collets Premium class tooling system for highest production efficiency - Made in GermanyCollet chuck ER40 DIN6499Clamping range ?4-26For collet 400 472EMaximum tightening torque: 160 NmTechnical featureCover not convertible.It is not possible to change the machining direction, with the help of the cover, between the main spindle or the counter spindle.

31.4032DHWA - Collet chuck holder, Shank- ?40, For collets 320 470E

Tool holder for collets Premium class tooling system for highest production efficiency - Made in GermanyCollet chuck ER32 DIN6499Clamping range ?3-20For collet 320 470EMaximum tightening torque: 120 Nm

WA4030G300RL - Adaptor, Shank- ?40, Adaptor VDI30

Double toothing (Traub license)VDI shank double toothed.Tool holder can be rotated 180°.Note: Rotatability may be restricted by alignment systems (e.g. Trifix).

WA3030MFSRL - Adaptor, Shank- ?30, Adaptor VDI30

Double toothing (Traub license)VDI shank double toothed.Tool holder can be rotated 180°.Note: Rotatability may be restricted by alignment systems (e.g. Trifix).

19.25ABS50G200RL - Tool adaptor, ABS 50 ( Licence Komet ), Double serration,

Boring Bar Holder Premium class tooling system for highest production efficiency - Made in GermanyDouble toothing (Traub license)VDI shank double toothed.Tool holder can be rotated 180°.Note: Rotatability may be restricted by alignment systems (e.g. Trifix).

17.3032TS46 - Combi holder for int/ext. cooling, hole -? 32 mm,

Combination holder for internal and external cooling Premium class mold system for highest production efficiency - Made in Germany

WA3030LE365R - Adaptor, Shank- ?30, Adaptor VDI30

Adaptor VDI 30 adaptor Weight: 4.504

20.3032LDCTX - Boringbar holder, Shank- ?30, hole -? 32 mm

Boring bar holder, slotted Premium class tooling system for highest production efficiency - Made in GermanyTechnical featureCover not convertible.It is not possible to change the machining direction, with the help of the cover, between the main spindle or the counter spindle.

PH31.25.425-ZYL - Floating holder, Shank- ?25.4, For collets 250 430E

Pendulum holder Premium class tooling system for highest production efficiency - Made in GermanyCollet chuck ER25 DIN6499Clamping range ?2-16For collet 250 430EMaximum tightening torque: 90 Nm

19.2525MFTRZ0 - Tool adaptor, hole -? 25 mm, right hand, Z=0 mm, Cover not convertible

Boring Bar Holder Premium class tooling system for highest production efficiency - Made in GermanyTechnical featureCover not convertible.It is not possible to change the machining direction, with the help of the cover, between the main spindle or the counter spindle.
