| Function | Vibration analysis in time domainContact temperature monitoring |
| Vibration, frequency range | 2…4500 Hz (±10 %)2…6000 Hz (±3 dB) |
| Vibration, number of measuring axes | 3 |
| Vibration, measuring range | -16…16 g |
| Contact temperature, measuring range | -40…+80 °C |
| Rated operating voltage Ue DC | 24 V |
| Interface | IO-Link 1.1.3 |
| Connection | Cable with connector, M12x1-Male, 4-pin, 1.5 m, PUR |
| Housing material | Stainless steel 1.4404 (316L) |
| IP rating | IP67, IP68, IP69K |
| Ambient temperature | -40…80 °C |
| Secondary features | IdentificationDevice DiscoverySwitching CounterOperating Hours CounterBoot Cycle CounterVoltage and Current MonitoringPin Assignment |
| Secondary features for condition monitoring | Internal temperature monitoring |
